Correct Fitment of WIR5243 to PAD1448 on the rear of Jaguar XF & XJ models



To correctly fit the wear sensor, first remove the pad spring fitting from the top of the pad using a suitable tool.

Screen Shot 2017-03-28 at 09.19.11

Insert the wear sensor into the spring.Screen Shot 2017-03-28 at 09.20.19

Insert the spring and wear sensor back it to the pad using a suitable tool.Screen Shot 2017-03-28 at 09.22.56

Pay special attention, not to apply force on top of the plastic sensor housing during this step to avoid damaging the sensor housing.

Screen Shot 2017-03-28 at 09.23.51
